Introduction
This machine is widely used in food, electronic accessories, cigarettes, cosmetics, condoms etc. For single box or integrated packaging production lines. It's well received in customers from all of the world. Because of its good performance.
The main features
1. Automatic feeding, conveying, stacking,
coating, forming, sealing, counting, etc..
2. The machine can be used independently or can be used as an automatic production line with
laser marking machine, cartoning Machine etc..
3.The use of folding angle packaging make it more perfect and improve anti-counterfeiting
ability
4. In the packaging process, when supplying box, the machine can automatically turn on;
otherwise stop when there is no box.
5. Simple operation, the packaging form can be customized. and the size can be adjusted in the
range of packaging.
6. Measuring instrument and apparatus are in accordance with the legal measurement units
7. The machine has compact structure, advanced performance, stable running, high efficiency,
energy saving, stepless speed regulation.
Model
TMB-300E
Speed of Packing
(10-30)packing boxes per minute
Packing size range(mm)
Length(350-80)×Width(240-40)×Height(125-15)mm
Packing film
BOPP, PVC
Thickness
0.021-0.028mm
Width
Based on the dimension of box
Sealing temperature
100-150ºC
Power supply
50HZ/AC380V
Total power
3.5KW
Working pressure
≥0.3MPa
Integrated noise
<69dB(A)
Dimensions
1800-850-1200mm
Weight of machine
500kg
1. Automatic feeding, conveying, stacking,
coating, forming, sealing, counting, etc..
2. The machine can be used independently or can be used as an automatic production line with
laser marking machine, cartoning Machine etc..
3.The use of folding angle packaging make it more perfect and improve anti-counterfeiting
ability
4. In the packaging process, when supplying box, the machine can automatically turn on;
otherwise stop when there is no box.
5. Simple operation, the packaging form can be customized. and the size can be adjusted in the
range of packaging.
6. Measuring instrument and apparatus are in accordance with the legal measurement units
7. The machine has compact structure, advanced performance, stable running, high efficiency,
energy saving, stepless speed regulation.
| Model | TMB-300E |
| Speed of Packing | (10-30)packing boxes per minute |
| Packing size range(mm) | Length(350-80)×Width(240-40)×Height(125-15)mm |
| Packing film | BOPP, PVC |
| Thickness | 0.021-0.028mm |
| Width | Based on the dimension of box |
| Sealing temperature | 100-150ºC |
| Power supply | 50HZ/AC380V |
| Total power | 3.5KW |
| Working pressure | ≥0.3MPa |
| Integrated noise | <69dB(A) |
| Dimensions | 1800-850-1200mm |
| Weight of machine | 500kg |
Certifications
Our Exhibition
Packing & Delivery
Any questions about the machine, please contact with me.
1.what's the delivery time?
3.Are you a manufacturer?
--Yes,We have been packaging machinery over 14 years.
4.what about the payment term ?
--Mostly 30%T/T in advanced,the rest need paid before shipping.
5.What information should i let you know if i want to get a quotation?
--Quantity--What's the bag size?
--What's the unfold wipe size ?
--What's the folding way ?
--how many ml of each bag?
--What's the inner material and outter material ?
6.what's your advantages ?
--17 years experience:We have been in making machinery for 17 years.
--Customers all over the world
--Certificate: CE certificate
--Fast reply:Our team will reply you soon.
--After-sale service:We have a after sale department , service for your problems and dealing with spare parts.
